Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Raleigh
2017 Raleigh RXC
Value Guide market data · 2017 Raleigh RXC
12-month trend
12%
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2017 Raleigh RXC
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All RXC model years
2017 RXC lineup
Overview
About this bike
2017 Raleigh RXC value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Frame
- Direct Connect Carbon w/ Flat-Mount Disc Frame, 142x12 Thru-Axle, Tapered HT, Di2 or Mechanical Compatible
- Fork
- Raleigh Carbon Flat Mount Disc Cross Fork, Tapered 1-1/8" to 1.5", 15mm Thru Axle
- Fork Brand & Model
- Raleigh Carbon Flat Mount Disc Cross Fork, Tapered 1-1/8inch to 1.5inch
- Frame Construction
- Direct Connect Carbon w/ Flat-Mount Disc Frame, Tapered HT, Di2 or Mechanical Compatible
Drivetrain
- Groupset
- SRAM Force
- Cranks
- Sram Force 1 w/ X-SYNC 42t Ring
- Bottom Bracket
- Sram GXP
- Rear Derailleur
- Sram Force
- Chain
- Sram PC-1170 11spd
- Shifter
- Sram Force Hydro Road Disc
- Cassette
- SRAM PG-1170, 11-speed: 11-32
- Chainrings
- 42t
- Crankset
- SRAM Force 1
- Shifters
- SRAM Force Hydro Road Disc
Brakes
- Brake Levers
- Sram Force Hydro
- Brakes
- Sram Force Hydro Flat Mount Road Disc, w/160mm Front, 140mm Rear
Cockpit
- Handlebar
- FSA SL-K COMPACT, Widths:40/42/42/44/44/44cm
- Stem
- FSA SLK, Lengths:90/90/100/100/110/110mm
- Seatpost
- FSA K-Force Carbon Monocoque, 27.2 25mm SB
- Seat
- Prologo Nago Evo Custom Raleigh Blue, 141mm wide
- Headset
- FSA Integrated Cartridge Bearings
- Saddle
- Prologo Nago Evo Custom Raleigh Blue, 141mm wide
Wheels & Tires
- Rims
- American Classic Hurricane Tubeless Disc Wheelset, 22mm Wide and 24mm Deep
- Tires
- Clement PDX Tubeless, 700x33, Folding
- Front Hub
- American Classic Hurricane 15mm Thru Axle, Disc
- Rear Hub
- American Classic Hurricane 142x12mm Thru Axle, Disc
- Spokes
- American Classic
- Hubs
- Front: American Classic Hurricane 15mm Thru Axle, Disc; Rear: American Classic Hurricane 142x12mm Thru Axle, Disc
- Wheel Set
- American Classic Hurricane Tubeless Disc Wheelset, 22mm Wide and 24mm Deep
Pedals
- Pedals
- Test Ride Pedals
Accessories
- Extras
- CDS Plates, AC Tubeless Valves
- Cogset
- Sram PG-1170 11-32 11spd
Weight & Sizing
- *Bike Size
- Choose an Option...
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
