Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Trek
2026 Trek Domane+ ALR 5
Previous used estimate
$3,973 - $4,088
Actual value depends on condition, size, and local demand.
Value Guide market data · 2026 Trek Domane+ ALR 5
12-month projected trend
6%
Direction and magnitude, not judgment
vs. category average
25%
Drops faster than category avg
Price over time - 2026 Trek Domane+ ALR 5
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Domane+ model years
Compare Domane+ ALR 5 models
1 modelsChoose a different build or frame style to see its value.
Overview
About this bike
Domane+ ALR 5 is an aluminum electric road bike with a smooth, quiet, and natural-feeling boost. Its TQ HPR60 motor gives you plenty of support for long rides and big climbs, and pairs with a SRAM Apex 12-speed drivetrain for clean, consistent shifts.
Specifications
- Subtype
- Electric Road
- Category
- E-Bike
- Component Fork
- Domane+ carbon, tapered carbon steerer, fender mounts, flat mount disc, 12x100mm thru axle
- Component Hubs
- Front: Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle Rear: Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
- Component Rims
- Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23mm width, Presta valve
- Component Size
- X-Small, Small, Medium, Medium/Large, Large, X-Large
- Component Stem
- X-Small: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length. Small: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length. Medium: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length. Medium/Large - Large: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length. X-Large: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length
- Product Family
- Domane+
- Component Chain
- SRAM Apex, 12 speed
- Component Color
- Matte Dark Star, Plasma Grey Pearl
- Component Frame
- 300 Series Alpha Aluminum, TQ drive system, hidden fender mounts, rack mounts, integrated frame bag mounts, internal cable routing, flat mount disc, integrated chainkeeper, UDH, 142x12mm chamfered thru axle
- Component Motor
- TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
- Component Brakes
- SRAM Apex D1 hydraulic disc, flat mount
- Component Rotors
- SRAM Paceline, rounded, centerlock, 160mm
- Component Saddle
- Verse Short Comp, steel rails, 145mm width
- Component Spokes
- 14g stainless steel, black
- Component Battery
- TQ 360Wh
- Component Charger
- TQ 4A charger
- Component Crankset
- Small - X-Small: Praxis Alloy, 165mm length Medium - Medium/Large: Praxis Alloy, 170mm length Large - X-Large: Praxis Alloy, 172.5mm length
- Component Seatpost
- Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- Component Shifters
- SRAM Apex, 12 speed
- Component Handlebar
- X-Small: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width. Small: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width. Medium - Medium/Large: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm drop width. X-Large - Large: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width
- Component Rear Tire
- Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm
- Component Front Tire
- Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm
- Component Tape Grips
- Trek EcoTack
- Component Wheel Size
- 700c
- Component Brake Levers
- SRAM Apex, 12 speed
- Component Rear Derailleur
- SRAM Apex XPLR, 44T max cog
- Component Cassette Freewheel
- SRAM XPLR PG-1231, 11-44, 12 speed
- Component Controller Display
- TQ color LED display with Bluetooth & ANT+ connectivity
- Hubs
- Front: Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle Rear: Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
- Rims
- Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23mm width, Presta valve
- Crankset
- Small - X-Small: Praxis Alloy, 165mm length Medium - Medium/Large: Praxis Alloy, 170mm length Large - X-Large: Praxis Alloy, 172.5mm length
- Chain
- SRAM Apex, 12 speed
- Seatpost
- Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- Saddle
- Verse Short Comp, steel rails, 145mm width
- Handlebar
- X-Small: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width. Small: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width. Medium - Medium/Large: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm drop width. X-Large - Large: Bontager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width
- Rear Derailleur
- SRAM Apex XPLR, 44T max cog
- Rear Tire
- Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm
- Stem
- X-Small: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length. Small: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length. Medium: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length. Medium/Large - Large: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length. X-Large: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length
- Brake Levers
- SRAM Apex, 12 speed
- Brakes
- SRAM Apex D1 hydraulic disc, flat mount
- Fork
- Domane+ carbon, tapered carbon steerer, fender mounts, flat mount disc, 12x100mm thru axle
- Frame
- 300 Series Alpha Aluminum, TQ drive system, hidden fender mounts, rack mounts, integrated frame bag mounts, internal cable routing, flat mount disc, integrated chainkeeper, UDH, 142x12mm chamfered thru axle
- Shifters
- SRAM Apex, 12 speed
- Tape/Grips
- Trek EcoTack
- Motor
- TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
- Charger
- TQ 4A charger
- Battery
- TQ 360Wh
- Color
- Plasma Grey Pearl
- Size
- X-Large
- Wheel Size
- 700c
- Spokes
- 14g stainless steel, black
- Cassette/Freewheel
- SRAM XPLR PG-1231, 11-44, 12 speed
- Controller/Display
- TQ color LED display with Bluetooth & ANT+ connectivity
- Rotors
- SRAM Paceline, rounded, centerlock, 160mm
- Front Tire
- Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Battery health
Request battery cycle count, capacity diagnostics, and motor service records.
