Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Diamondback
2017 Diamondback Haanjo
Value Guide market data · 2017 Diamondback Haanjo
12-month trend
10%
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2017 Diamondback Haanjo
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Haanjo model years
2017 Haanjo lineup
Overview
About this bike
2017 Diamondback Haanjo value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Fork
- DB Alloy Gravel Disc w/ 1.5" Tapered Steerer Tube
- Frame
- DB Alternative Road, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, Tapered Headtube, Disc Only w/ Replaceable Hanger
Drivetrain
- Groupset
- Shimano Sora
- Cranks
- FSA Gossamer Cross Mega Exo, 46/36T
- Bottom Bracket
- FSA Mega Exo
- Front Derailleur
- Shimano Sora FD-3500, 31.8 Band Clamp
- Rear Derailleur
- Shimano Sora RD-R3000, 9 Speed
- Chain
- KMC Z99, 9 Speed
- Shifter
- Shimano Sora SL-3500, Flat Bar, 2x9 Speed
- Cassette
- Shimano Tiagra HG50, 9 Speed: 11-32
- Chainrings
- 46/36
- Crankset
- FSA Gossamer Cross Mega Exo
- Shifters
- Shimano Sora SL-3500, Flat Bar, 2×9 Speed
Brakes
- Brake Levers
- Tektro 2 Finger Alloy Linear, For Flat Mount Disc
- Brakes
- Tektro Lyra Flat Mount Mechanical Disc, w/ 160mm Front / 140mm Rear Rotors
Cockpit
- Handlebar
- DB Flat Bar, 680mm Wide, 31.8mm Bar Bore
- Stem
- HED Eroica, 6061 Alloy, 3D Forged, +/-7° Rise, 31.8 Bar Bore
- Seatpost
- HED Eroica, 6061 Alloy, 27.2mm
- Seat
- DB Eldorado
- Headset
- FSA NO.42, Sealed Cartridge for Tapered Headtube
- Grips
- Diamondback Dual Density Grip
- Saddle
- DB Eldorado
Wheels & Tires
- Rims
- DB Equation CX 700c 28h, Double Wall
- Tires
- Kenda Flintridge, 700x40c
- Front Hub
- 28h Alloy w/ CNC Disc Mount
- Rear Hub
- 28h Alloy w/ CNC Disc Mount, Cassette
- Spokes
- 14g Stainless Steel
- Hubs
- Aluminum w/CNC disc mount
- Wheel Set
- DB Equation CX 700c 28h, Doublewall
Pedals
- Pedals
- DB Laser Alloy Platform
Accessories
- Extras
- Owner’s Manual, Assembly Guide, Bottle Cages, Tool Kit*
- Cogset
- Shimano Tiagra HG50, 9 Speed, 11-32T
- Accessories & Extras
- Bottle cages
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
