Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Raleigh
2018 Raleigh Eva 24
Value Guide market data · 2018 Raleigh Eva 24
12-month trend
— %
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2018 Raleigh Eva 24
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Eva model years
2018 Eva 24 lineup
Overview
About this bike
2018 Raleigh Eva 24 value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Frame
- Aluminum / 24" Low Standover 6061 Aluminum w/Replaceable Hanger
- Suspension
- Hardtail, 50mm
- Fork
- SR Suntour XCT 50mm TravelTravel:50mmSpring Type:Coil
- Headset
- 1-1/8" Threadless
Drivetrain
- Drivetrain
- 1 × 7
- Groupset
- Tourney
- Crank Length
- 160
- Bottom Bracket
- Sealed Mech Loose Ball
- Rear Derailleur
- Shimano TX-35
- Crank
- 150mm Lasco AL 32t single ring w/ dual chainring guards
- Shifters
- Shimano Revo 7spd
- Cassette
- 7spd 13-32
- Chain
- KMC Z51
Brakes
- Brakes
- Rim / Alloy V-BrakeType:Rim
- Brake Levers
- Promax Alloy Youth Lever
Cockpit
- Stem Length
- 60
- Handlebar Width
- 580
- Stem
- 60mm Alloy Ahead
- Handlebar
- 580mm Alloy, 30mm Rise
- Saddle
- Jr. Mountain
- Seatpost
- Alloy Micro Adjust 27.2 x 300mmType:Rigid
- Grips
- Jr. Soft PVC
Wheels & Tires
- Wheels
- 24″ Aluminum / 24″
- Top Tube Length
- 510
- Seat Tube Length
- 330
- Seat Tube Angle
- 71.0
- Head Tube Length
- 100
- Head Tube Angle
- 70.0
- Rims
- Alloy Anodized 32h
- Spokes
- 14g
- Front Hub
- Alloy 32h w/QR
- Rear Hub
- Alloy 32h w/QR, Freewheel
- Tires
- 24x1.95"
Pedals
- Pedals
- Resin Platform
Accessories
- Stack
- 570
- Reach
- 386
- Stack/Reach Ratio
- 1.48
- BB Drop
- 35
- Front Center
- 551
- Chainstay Length
- 410
- Wheelbase
- 958
- Rake
- 40
- Standover Height
- 640
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
