Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Jamis
2022 Jamis Faultline A1
Previous used estimate
$1,195 - $1,230
Actual value depends on condition, size, and local demand.
Value Guide market data · 2022 Jamis Faultline A1
12-month projected trend
11%
Direction and magnitude, not judgment
vs. category average
4%
Drops faster than category avg
Price over time - 2022 Jamis Faultline A1
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Faultline model years
Compare Faultline A1 models
1 modelsChoose a different build or frame style to see its value.
Overview
About this bike
MP2 SUSPENSION Dual suspension platforms open up a whole new world of on-trail speed and control. Faultline combines our proven MP2 design, the suspension platform that's won us numerous industry accolades, and Bike of the Year awards, with 29? wheels and a smart spec. It's the perfect rig for the experienced hardtail rider looking to upgrade to a dual suspension bike, or for a new rider looking for a bit of a head start. ASYMMETRICAL CHAINSTAYS The Faultline's chainstays are asymmetrical, with an elevated straight stay on the non-drive side and a dropped curved stay on the drive side. The drive side must be dropped & curved to clear the chainring, but running the non-drive side straight from the dropout to BB pivot reduces weight while significantly stiffening the rear triangle laterally. This design also helps improve tire clearance. - Triple-butted 6061 alloy - 120mm travel mp2 suspension - Rock Shox Deluxe Select+ RL air shock with rebound adjust & lock out - Rock Shox 35 Gold RL 29”, Solo Air, lever actuated lockout, external rebound - Stan’s No Tubes Arch D 29” tubeless rims, Shimano SLX hubs - Shimano SLX, 12-speed - Race Face Ride, 32T crank - Shimano MT401 hydraulic disc brakes
Specifications
- Subtype
- Trail / Enduro
- Category
- Mountain
- Component Fork
- Rock Shox 35 Gold RL 29”, Solo Air compression, lever actuated lockout, external rebound, 35mm aluminum stanchions, magnesium lowers, 15x110mm axle, 130mm travel, 51mm rake
- Component Size
- 15-inch, 17-inch, 19-inch, 21-inch
- Component Stem
- Race Face Ride
- Product Family
- Faultline
- Component Chain
- KMC X12, 12-speed
- Component Color
- Thunder Grey
- Component Frame
- Triple-butted 6061 alloy, 120mm travel mp2 suspension, 1.5 – 1 1/8” tapered head tube, asymmetrical chainstays w/12x148mm thru-axle dropout, internal dropper post routing, ISCG05 chainguide mount, Rock Shox Deluxe Select+ RL air shock with rebound adjust & lock out, replaceable derailleur hanger
- Component Brakes
- Shimano MT401 hydraulic disc, 180mm front & 160mm rear RT30 rotors
- Component Pedals
- Sold separately
- Component Saddle
- WTB Volt
- Component Headset
- FSA Orbit 1.5 Zero-Stack internal cup, 8mm cone spacer
- Component Crankset
- Race Face Ride, 32T
- Component Seatpost
- KS Rage Dropper, Southpaw remote
- Component Shifters
- Shimano SLX, 1×12-speed
- Component Handlebar
- Race Face Ride
- Component Rear Tire
- WTB Vigilante 29 x 2.35” Front & Trail Boss 29 x 2.25” Rear, TCS Tubeless
- Component Wheel Set
- Stan’s No Tubes Arch D 29” tubeless rims, 32H, Shimano SLX 15x110mm front & 12x148mm rear hubs, stainless spokes
- Component Front Tire
- WTB Vigilante 29 x 2.35” Front & Trail Boss 29 x 2.25” Rear, TCS Tubeless
- Component Tape Grips
- Jamis Lock-On
- Component Bottom Bracket
- Race Face BSA
- Component Rear Derailleur
- Shimano SLX, 12-speed
- Component Cassette Freewheel
- Shimano M7100, 12-speed, 10-51T
- Crankset
- Race Face Ride, 32T
- Pedals
- Sold separately
- Bottom Bracket
- Race Face BSA
- Chain
- KMC X12, 12-speed
- Seatpost
- KS Rage Dropper, Southpaw remote
- Saddle
- WTB Volt
- Handlebar
- Race Face Ride
- Headset
- FSA Orbit 1.5 Zero-Stack internal cup, 8mm cone spacer
- Rear Derailleur
- Shimano SLX, 12-speed
- Rear Tire
- WTB Vigilante 29 x 2.35” Front & Trail Boss 29 x 2.25” Rear, TCS Tubeless
- Stem
- Race Face Ride
- Brakes
- Shimano MT401 hydraulic disc, 180mm front & 160mm rear RT30 rotors
- Fork
- Rock Shox 35 Gold RL 29”, Solo Air compression, lever actuated lockout, external rebound, 35mm aluminum stanchions, magnesium lowers, 15x110mm axle, 130mm travel, 51mm rake
- Frame
- Triple-butted 6061 alloy, 120mm travel mp2 suspension, 1.5 – 1 1/8” tapered head tube, asymmetrical chainstays w/12x148mm thru-axle dropout, internal dropper post routing, ISCG05 chainguide mount, Rock Shox Deluxe Select+ RL air shock with rebound adjust & lock out, replaceable derailleur hanger
- Shifters
- Shimano SLX, 1×12-speed
- Tape/Grips
- Jamis Lock-On
- Color
- Thunder Grey
- Size
- 21-inch
- Cassette/Freewheel
- Shimano M7100, 12-speed, 10-51T
- Wheel Set
- Stan’s No Tubes Arch D 29” tubeless rims, 32H, Shimano SLX 15x110mm front & 12x148mm rear hubs, stainless spokes
- Front Tire
- WTB Vigilante 29 x 2.35” Front & Trail Boss 29 x 2.25” Rear, TCS Tubeless
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Suspension service
Confirm fork and rear shock service intervals and check pivot bearings for play.
