Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Marin
2024 Marin Bobcat Trail 5
Value Guide market data · 2024 Marin Bobcat Trail 5
12-month trend
18%
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2024 Marin Bobcat Trail 5
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Bobcat Trail model years
2024 Bobcat Trail 5 lineup
Overview
About this bike
2024 Marin Bobcat Trail 5 value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Fork
- SR/Suntour XCR LOR-DS BOOST, Thru-Axle, 120mm Travel, Lockout, 42mm (27.5") and 46mm (29") Offsets
- Frame
- Series 2 6061 Aluminum, 27.5" or 29” Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing & Dropper Post Routing
Drivetrain
- Groupset
- Shimano CUES
- Crankset
- Marin Forged Alloy w/ Hollow Spindle and Integrated Steel 32t Narrow Wide Chanring
- Bottom Bracket
- External Sealed Cartridge Bearings
- Chain
- KMC X11
- Cassette
- SunRace 11-Speed, 11-51T
- Derailleur, Rear
- Shimano Deore 11-Speed w/Clutch
- Shift Lever
- Shimano Deore 11-Speed
- Rear Derailleur
- Shimano CUES U6000GS, w/Clutch
- Shifters
- Shimano CUES 11-Speed
Brakes
- Brake Levers
- Shimano BL-MT201
- Brake, Front
- Shimano BR-MT201 Hydraulic Disc, 180mm Rotor
- Brake, Rear
- Shimano BR-MT201 Hydraulic Disc, 160mm Rotor
- Brakes
- Tektro M280 Hydraulic Disc, 180/160mm Rotor
Cockpit
- Handlebar
- Marin 31.8 Riser, 12mm Rise, 780mm Width
- Stem
- Marin Alloy, 31.8mm Clamp, 45mm
- Grips
- Marin MTB, Closed End
- Headset
- FSA No.10-P
- Seatpost
- Marin Alloy, 30.9
- Saddle
- Marin MTB
Wheels & Tires
- Rims
- Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
- Tires
- MTB, 27.5/29x2.25"
- Hub, Rear
- Forged Alloy, Disc, 32H
- Hub, Front
- Forged Alloy, Disc, 32H
- Spoke, Nipples
- 14g Black Stainless Steel
- Front Tire
- WTB Trail Boss Comp, 27.5/29x2.25”, Wire Bead
- Hubs
- Forged Alloy, Disc, 32H
- Rear Tire
- WTB Trail Boss Comp, 27.5/29x2.25”, Wire Bead
- Spokes
- 14g Black Stainless Steel
- Wheel Size
- 27.5-inch
Pedals
- Pedals
- Nylon Platform
Accessories
- M (27.5/29)
- 165cmto175cm
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Suspension service
Confirm fork lowers and rear shock service intervals; ask for the most recent service receipts.
Inspection
Frame pivots & bearings
Cycle the suspension off the bike to feel for play, grit, or noise in pivot bearings.
