Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Diamondback
2021 Diamondback Haanjo 3
Value Guide market data · 2021 Diamondback Haanjo 3
12-month trend
15%
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2021 Diamondback Haanjo 3
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Haanjo model years
2021 Haanjo 3 lineup
Overview
About this bike
2021 Diamondback Haanjo 3 value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Fork
- DB SPF Formed Aluminum Gravel Disc w/1.5" Tapered Steerer Tube
- Frame
- DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc, Replaceable Hanger
Drivetrain
- Groupset
- 2021 Diamondback Haanjo 3
- Crankset
- FSA Omega Adventure, 46/30T
- Bottom Bracket
- FSA Mega Exo
- Chain
- KMC Z9, 9 Speed
- Front Derailleur
- Shimano Sora FD-R3000, 31.8mm Band Clamp
- Rear Derailleur
- Shimano Sora RD-R3000, 9 Speed, GS
- Shifters
- Shimano Sora ST-R3000, 2x9 Speed
- Cassette/Freewheel
- Shimano HG400, 9 Speed Cassette, 11-32T
Brakes
- Brake Levers
- Shimano Sora ST-R3000
- Brakes
- Tektro Lyra Flat Mount Mechanical Disc, w/160mm Front / 160mm Rear Rotors
Cockpit
- Seatpost
- HED Eroica, 6061 Aluminum 27.2mm
- Saddle
- Diamondback Performance Gravel Road
- Handlebar
- HED Eroica, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
- Headset
- FSA No.42B, Sealed Cartridge
- Stem
- HED Eroica, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8mm Bar Bore
- Tape/Grips
- Diamondback Endurance Gel Tape
Wheels & Tires
- Hubs
- Front: 28h Aluminum Quick Release<br>Rear: 28h Aluminum Quick Release, Cassette
- Rims
- Diamondback Equation CX, 28h, Doublewall
- Rear Tire
- WTB Riddler Comp, 700x37c
- Spokes
- 14g Stainless Steel
- Front Tire
- WTB Riddler Comp, 700x37c
Pedals
- Pedals
- DB Resin Gravel Platform
Accessories
- Accessories & Extras
- Tool Kit
- Color
- Amber Gloss
Weight & Sizing
- Size
- X-Small / Small / Medium / Large / X-Large
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Carbon inspection
Tap test the frame, fork, seatpost, and bars for cracks; verify no impact damage near dropouts.
Inspection
Brake hoses & cables
Check hydraulic line bleed, cable housing wear, and confirm rotors are within spec.
