- Subtype
- Adventure & Touring
- Category
- Road
- Component Fork
- Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5" hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets
- Component Hubs
- Formula alloy Centerlock sealed bearing hubs, 32H
- Component Size
- 44cm, 48cm, 51cm, 54cm, 56cm, 58cm, 61cm
- Component Stem
- Ritchey 4-Axis 3D forged 6061 alloy, 6-deg x 70mm (44), 80mm (48/51), 90mm (54/56), 110mm (58/61)
- Product Family
- Renegade
- Component Axles
- Front: 12mm
Rear: 12 x 142mm
- Component Chain
- Shimano CN-HG601
- Component Color
- Ano Palladium
- Component Frame
- Jamis Size Specific Design frame geometry, Reynolds 631 double-butted chromoly main tubes, 44mm head tube for tapered fork, threaded BB shell, Jamis MTS (Modular Thru-axle System), flat mount disc brake mounts, top tube mounted full cable housing, dropper post cable guides, 3 waterbottle mounts, rack and fender eyelets, clearance for 700x42c and 650x47c tires.
- Component Brakes
- Shimano BR-RS505 hydraulic disc brakes with resin pads, Centerlock Ice Tech 160mm rotors
- Component Saddle
- Selle Royal Seta S1 with integrated clip system
- Component Headset
- FSA Orbit ITA B Internal/External, 1.5 - 1 1/8"
- Component Cassette
- Shimano 105 11-speed, 11-32T
- Component Crankset
- Shimano 105 FC-5800 compact double
- Component Shifters
- Shimano RS505 Dual Control STI, 22-speed
- Component Handlebar
- Ritchey Evomax Comp, 6061 aluminum, 73 reach, 120 drop with 12-deg flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)
- Component Seat Post
- Jamis carbon fiber micro-adjust, 27.2 x 330mm with cromo seat pin
- Component Chainrings
- 50/34
- Component Front Tire
- Clement X Plor MSO, 700 x 36c, 30TPI with protection belt
- Component Tape Grips
- Fizik Microtex Superlight Soft Touch with gel inserts
- Component Wheel Size
- 650B, 700C
- Component Brake Levers
- Shimano ST-RS505 Dual Control STI levers
- Component Bottom Bracket
- Shimano SM-BBR60
- Component Rear Derailleur
- Shimano 105 RD-5800 GS
- Component Front Derailleur
- 105 FD-5801 with 28.6mm alloy clamp
- Hubs
- Formula alloy Centerlock sealed bearing hubs, 32H
- Crankset
- Shimano 105 FC-5800 compact double
- Bottom Bracket
- Shimano SM-BBR60
- Chain
- Shimano CN-HG601
- Saddle
- Selle Royal Seta S1 with integrated clip system
- Handlebar
- Ritchey Evomax Comp, 6061 aluminum, 73 reach, 120 drop with 12-deg flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)
- Headset
- FSA Orbit ITA B Internal/External, 1.5 - 1 1/8"
- Front Derailleur
- 105 FD-5801 with 28.6mm alloy clamp
- Rear Derailleur
- Shimano 105 RD-5800 GS
- Stem
- Ritchey 4-Axis 3D forged 6061 alloy, 6-deg x 70mm (44), 80mm (48/51), 90mm (54/56), 110mm (58/61)
- Axles
- Front: 12mm
Rear: 12 x 142mm
- Brake Levers
- Shimano ST-RS505 Dual Control STI levers
- Brakes
- Shimano BR-RS505 hydraulic disc brakes with resin pads, Centerlock Ice Tech 160mm rotors
- Cassette
- Shimano 105 11-speed, 11-32T
- Chainrings
- 50/34
- Fork
- Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5" hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets
- Frame
- Jamis Size Specific Design frame geometry, Reynolds 631 double-butted chromoly main tubes, 44mm head tube for tapered fork, threaded BB shell, Jamis MTS (Modular Thru-axle System), flat mount disc brake mounts, top tube mounted full cable housing, dropper post cable guides, 3 waterbottle mounts, rack and fender eyelets, clearance for 700x42c and 650x47c tires.
- Seat Post
- Jamis carbon fiber micro-adjust, 27.2 x 330mm with cromo seat pin
- Shifters
- Shimano RS505 Dual Control STI, 22-speed
- Tape/Grips
- Fizik Microtex Superlight Soft Touch with gel inserts
- Color
- Ano Palladium
- Size
- 61cm
- Wheel Size
- 700C
- Front Tire
- Clement X Plor MSO, 700 x 36c, 30TPI with protection belt
