- Subtype
- Adventure & Touring
- Category
- Road
- Component Fork
- Jamis Adventure ECO monocoque carbon composite, Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5" hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets
- Component Hubs
- Formula alloy 6-bolt hubs, 32H
- Component Size
- 44cm, 48cm, 51cm, 54cm, 56cm, 58cm, 61cm
- Component Stem
- Ritchey 4-Axis 3D forged 6061 alloy, 6Ës x 70mm (44), 80mm (48/51), 90mm (54/56), 110mm (58/61)
- Product Family
- Renegade
- Component Axles
- Front: 12mm Thru A x le
Rear: Quick Release
- Component Chain
- KMC Z99
- Component Color
- Armor Green
- Component Frame
- Jamis Size Specific Design frame geometry, 6061 aluminum double-butted SST main frame, top tube mounted full cable housing, 1.5 - 1 1/8" tapered head tube, 31.8mm seat tube for 27.2 seat post, seat stay disc brake mounts, replaceable derailleur hanger, 3 waterbottle mounts, rack and fender eyelets, clearance for 700x42c and 650x47c tires.
- Component Brakes
- Tektro Lyra mechanical cable actuated disc brake with 160mm wave rotors
- Component Saddle
- Selle Royal Seta S1 with integrated clip system
- Component Headset
- FSA Orbit C-40B Internal/External, 1.5 - 1 1/8"
- Component Cassette
- Shimano HG400 9-speed, 11-32T
- Component Crankset
- FSA Vero
- Component Shifters
- Shimano Sora ST-R3000 Dual Control STI, 18-speed
- Component Handlebar
- Ritchey Evomax Comp, 6061 aluminum, 73 reach, 120 drop with 12° flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)
- Component Seat Post
- Jamis Road, micro-adjust, 27.2 x 350mm cromo seat pin
- Component Chainrings
- 50/34
- Component Front Tire
- Clement X Plor MSO 700 x 36c, 30TPI with protection belt
- Component Tape Grips
- Jamis suede tape with gel inserts
- Component Wheel Size
- 650B, 700C
- Component Brake Levers
- Shimano Sora ST-R3000 levers
- Component Bottom Bracket
- FSA sealed cartridge, 68 x 110.5mm
- Component Rear Derailleur
- Shimano Sora RD-R3000 GS
- Component Front Derailleur
- Sora FD-R3000 with 31.8mm alloy clamp
- Hubs
- Formula alloy 6-bolt hubs, 32H
- Crankset
- FSA Vero
- Bottom Bracket
- FSA sealed cartridge, 68 x 110.5mm
- Chain
- KMC Z99
- Saddle
- Selle Royal Seta S1 with integrated clip system
- Handlebar
- Ritchey Evomax Comp, 6061 aluminum, 73 reach, 120 drop with 12° flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)
- Headset
- FSA Orbit C-40B Internal/External, 1.5 - 1 1/8"
- Front Derailleur
- Sora FD-R3000 with 31.8mm alloy clamp
- Rear Derailleur
- Shimano Sora RD-R3000 GS
- Stem
- Ritchey 4-Axis 3D forged 6061 alloy, 6Ës x 70mm (44), 80mm (48/51), 90mm (54/56), 110mm (58/61)
- Axles
- Front: 12mm Thru A x le
Rear: Quick Release
- Brake Levers
- Shimano Sora ST-R3000 levers
- Brakes
- Tektro Lyra mechanical cable actuated disc brake with 160mm wave rotors
- Cassette
- Shimano HG400 9-speed, 11-32T
- Chainrings
- 50/34
- Fork
- Jamis Adventure ECO monocoque carbon composite, Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5" hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets
- Frame
- Jamis Size Specific Design frame geometry, 6061 aluminum double-butted SST main frame, top tube mounted full cable housing, 1.5 - 1 1/8" tapered head tube, 31.8mm seat tube for 27.2 seat post, seat stay disc brake mounts, replaceable derailleur hanger, 3 waterbottle mounts, rack and fender eyelets, clearance for 700x42c and 650x47c tires.
- Seat Post
- Jamis Road, micro-adjust, 27.2 x 350mm cromo seat pin
- Shifters
- Shimano Sora ST-R3000 Dual Control STI, 18-speed
- Tape/Grips
- Jamis suede tape with gel inserts
- Color
- Armor Green
- Size
- 61cm
- Wheel Size
- 700C
- Front Tire
- Clement X Plor MSO 700 x 36c, 30TPI with protection belt
