Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Trek
2019 Trek Checkpoint ALR 5
Previous used estimate
$664 - $683
Actual value depends on condition, size, and local demand.
Value Guide market data · 2019 Trek Checkpoint ALR 5
12-month projected trend
20%
Direction and magnitude, not judgment
vs. category average
1%
Drops faster than category avg
Price over time - 2019 Trek Checkpoint ALR 5
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Checkpoint model years
Compare Checkpoint ALR 5 models
2 modelsChoose a different build or frame style to see its value.
Overview
About this bike
Checkpoint ALR 5 is the best value gravel bike in the lineup. It's a high-quality build that will that hold up for long, rugged miles on pavement, dirt, and even the most treacherous gravel roads. But what sets this model apart is the performance parts and the wealth of features like adjustable Stranglehold dropouts, massive tire clearance, and extra mounts that make it easy to customize for your kind of adventure.
Specifications
- Subtype
- Gravel
- Category
- Road
- Component Fork
- Checkpoint carbon disc, alloy tapered steerer, flat mount disc brakes, rack mounts, hidden fender mounts, 12mm thru axle
- Component Hubs
- Bontrager alloy sealed bearing, Center Lock
- Component Size
- 49cm, 52cm, 54cm, 56cm, 58cm, 61cm
- Component Stem
- Bontrager Elite, 31.8mm clamp, 7 degree rise, w/computer & light mounts
- Product Family
- Checkpoint
- Component Axles
- 12mm alloy
- Component Color
- Solid Charcoal, Volt Green
- Component Frame
- 300 Series Alpha Aluminum, tapered head tube, BB86.5, flat mount disc brakes, Stranglehold dropouts, 12mm thru axle, Control Freak, internal control routing, 3S chain keeper
- Component Brakes
- Shimano RS505 flat mount hydraulic disc
- Component Saddle
- Bontrager Montrose Comp
- Component Headset
- Integrated, cartridge bearing, sealed, 1-1/8" top, 1.5" bottom
- Component Cassette
- Shimano HG800, 11-34, 11 speed
- Component Crankset
- Shimano 105
- Component Shifters
- Shimano RS505, 11 speed
- Component Handlebar
- Bontrager RL IsoZone VR-CF
- Component Seat Post
- Bontrager Approved, 2-bolt head, 27.2mm, 8mm offset
- Component Chainrings
- 50/34
- Component Front Tire
- Schwalbe G-One Allround, aramid bead, 700x35c
- Component Tape Grips
- Bontrager tape
- Component Bottom Bracket
- Shimano Press-fit
- Component Rear Derailleur
- Shimano 105
- Component Front Derailleur
- Shimano 105, braze-on
- Hubs
- Bontrager alloy sealed bearing, Center Lock
- Crankset
- Shimano 105
- Bottom Bracket
- Shimano Press-fit
- Saddle
- Bontrager Montrose Comp
- Handlebar
- Bontrager RL IsoZone VR-CF
- Headset
- Integrated, cartridge bearing, sealed, 1-1/8" top, 1.5" bottom
- Front Derailleur
- Shimano 105, braze-on
- Rear Derailleur
- Shimano 105
- Stem
- Bontrager Elite, 31.8mm clamp, 7 degree rise, w/computer & light mounts
- Axles
- 12mm alloy
- Brakes
- Shimano RS505 flat mount hydraulic disc
- Cassette
- Shimano HG800, 11-34, 11 speed
- Chainrings
- 50/34
- Fork
- Checkpoint carbon disc, alloy tapered steerer, flat mount disc brakes, rack mounts, hidden fender mounts, 12mm thru axle
- Frame
- 300 Series Alpha Aluminum, tapered head tube, BB86.5, flat mount disc brakes, Stranglehold dropouts, 12mm thru axle, Control Freak, internal control routing, 3S chain keeper
- Seat Post
- Bontrager Approved, 2-bolt head, 27.2mm, 8mm offset
- Shifters
- Shimano RS505, 11 speed
- Tape/Grips
- Bontrager tape
- Color
- Volt Green
- Size
- 61cm
- Front Tire
- Schwalbe G-One Allround, aramid bead, 700x35c
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
