Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Giant
2023 Giant Trance X Advanced E+ LTD
Value Guide market data · 2023 Giant Trance X Advanced E+ LTD
Market data not yet available
We don't have enough sales data for this exact bike yet. Try a different year or model, or get a personalized valuation.
Get a personalized valuation based on your bike's exact condition and specs.
All Trance model years
2023 Trance X Advanced E+ LTD lineup
Overview
About this bike
2023 Giant Trance X Advanced E+ LTD value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Frame
- Carbon / Advanced-Grade Composite front and rear triangles, 120mm Maestro suspension, flip chip - Maestro, 12x148mm thru-axle, integrated downtube storageBB Standard:BB86/BB92, Press FitTire Clearance:2.6"Color:Airglow
- Suspension
- Full, 120 / 130mm
- Fork
- Fox Rhythm Float 34 / Fox 34 Float Rhythm, 130mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for GiantTravel:130mmSpring Type:Air
- Shock
- Fox Float DPS Performance / Fox Float DPS Performance, 185/50, custom tuned for GiantTravel:120mm
Drivetrain
- Drivetrain
- 1 × 12
- Groupset
- SLX
- Bottom Bracket
- Shimano, press fit
- Rear Derailleur
- Shimano SLX RD-M7100
- Crank
- {S=165mm, M=170mm, L=170mm, XL=170mm}
- Shifters
- Shimano SLX SL-M7100, 1x12
- Cassette
- Shimano SLX, 10x51
- Chain
- KMC X-12
Brakes
- Brakes
- Shimano Deore Hydraulic Disc / Shimano Deore BR-M6120, hydraulic, Shimano RT-56 rotors [F]180mm, [R]180mmType:Shimano Deore Hydraulic Disc
- Brake Levers
- Shimano Deore BL-M6100
Cockpit
- Seatpost
- Dropper / TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mmType:Dropper
- Stem
- {S=40mm, M=40mm, L=50mm, XL=50mm}
- Handlebar
- Giant Contact SL TR35, 780x35mm
- Saddle
- Giant Romero SL
- Grips
- {S=120mm, M=120mm, L=130mm, XL=130mm}
Wheels & Tires
- Wheels
- 29″ Carbon
- Rims
- Giant TRX 2 29 Carbon WheelSystem, 30mm inner width
- Spokes
- Sapim
- Front Hub
- Front : Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
- Rear Hub
- Front : Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
- Tires
- [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubeless
Frame sizing
WheelsManufacturer sizing
StackManufacturer sizing
ReachManufacturer sizing
Stack/Reach RatioManufacturer sizing
Top Tube LengthManufacturer sizing
Seat Tube LengthManufacturer sizing
Seat Tube AngleManufacturer sizing
Head Tube LengthManufacturer sizing
Head Tube AngleManufacturer sizing
BB DropManufacturer sizing
BB HeightManufacturer sizing
Front CenterManufacturer sizing
Chainstay LengthManufacturer sizing
WheelbaseManufacturer sizing
RakeManufacturer sizing
TrailManufacturer sizing
Standover HeightManufacturer sizing
Stem LengthManufacturer sizing
Crank LengthManufacturer sizing
Handlebar WidthManufacturer sizing
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Battery health
Request battery cycle count and any diagnostic report; older packs lose range and capacity.
Inspection
Motor warranty
Verify motor warranty status and any firmware updates from the manufacturer dealer.
