- Subtype
- Trail / Enduro
- Category
- Mountain
- Component Fork
- 2018 RockShox Revelation RC 27.5-B Boost, 1-1/8 - 1.5in tapered alloy steerer, 35mm stanchions, Solo Air; 140mm travel
- Component Size
- 14.5-inch, 16-inch, 18-inch, 20.5-inch
- Component Stem
- Ritchey MTN Trail, 3D Forged, 0 DEG, 60/70mm
- Product Family
- Shift
- Component Axles
- 15x110mm (Front)
12x148mm (Rear)
- Component Chain
- KMC X11-1 NP/GY, 1 x11 specific w/ Missing Link
- Component Color
- Electric Red/Black
- Component Frame
- 6061-T6 series alloy dual suspended 4-Bar linkage frame, 27.5-inch Plus / 29-inch geometry, 130mm rear travel, tapered 1.5-inch head tube, Enduro bearings
- Component Brakes
- Shimano SLX hydraulic, BR-M7000, 180/160mm rotors
- Component Saddle
- WTB Rocket Comp
- Component Headset
- Comp Logic Zero Press-Fit 1-1/8-inch / 1.5", Semi-Cartridge bearings, for 44/56mm head tube (28.6/41-39.8/56mm)
- Component Cassette
- Shimano XT CS-M8000, 11-spd 11-46T
- Component Crankset
- V-Drive Modular Boost Compatible
- Component Shifters
- Shimano Deore XT, SL-M8000-R, Right, 11-Speed, Clamp w/o gear display
- Component Handlebar
- Ritchey MTN Trail Low Riser, 20mm rise, 740 / 760mm wide; 9 Deg. sweep
- Component Seat Post
- Tranz-X Internal Dropper post w/ shifter-type remote, 7075 alloy, 31.6x100x360MM / 80x315MM for 14.5-inch frame
- Component Chainrings
- 30T Megatooth Chromoly Chainring
- Component Front Tire
- WTB Ranger, 27.5 x 2.8, Dual DNA, TCS, Aramid Bead 60 tpi
- Component Tape Grips
- Ritchey MTN Trail WCS LockRing, 135mm
- Component Brake Levers
- Shimano SLX hydraulic, BL-M7000
- Component Bottom Bracket
- FSA MegaExo 73mm Boost sealed cartridge
- Component Rear Derailleur
- Shimano XT RD-M8000 GS 11-spd Shadow Plus design
- Component Accessories Extras
- Pivit alloy 35mm quick release seatpost clamp, Mr. Control alloy direct mount plate cover & upper chain guide
- Crankset
- V-Drive Modular Boost Compatible
- Bottom Bracket
- FSA MegaExo 73mm Boost sealed cartridge
- Chain
- KMC X11-1 NP/GY, 1 x11 specific w/ Missing Link
- Saddle
- WTB Rocket Comp
- Handlebar
- Ritchey MTN Trail Low Riser, 20mm rise, 740 / 760mm wide; 9 Deg. sweep
- Headset
- Comp Logic Zero Press-Fit 1-1/8-inch / 1.5", Semi-Cartridge bearings, for 44/56mm head tube (28.6/41-39.8/56mm)
- Rear Derailleur
- Shimano XT RD-M8000 GS 11-spd Shadow Plus design
- Stem
- Ritchey MTN Trail, 3D Forged, 0 DEG, 60/70mm
- Accessories & Extras
- Pivit alloy 35mm quick release seatpost clamp, Mr. Control alloy direct mount plate cover & upper chain guide
- Axles
- 15x110mm (Front)
12x148mm (Rear)
- Brake Levers
- Shimano SLX hydraulic, BL-M7000
- Brakes
- Shimano SLX hydraulic, BR-M7000, 180/160mm rotors
- Cassette
- Shimano XT CS-M8000, 11-spd 11-46T
- Chainrings
- 30T Megatooth Chromoly Chainring
- Fork
- 2018 RockShox Revelation RC 27.5-B Boost, 1-1/8 - 1.5in tapered alloy steerer, 35mm stanchions, Solo Air; 140mm travel
- Frame
- 6061-T6 series alloy dual suspended 4-Bar linkage frame, 27.5-inch Plus / 29-inch geometry, 130mm rear travel, tapered 1.5-inch head tube, Enduro bearings
- Seat Post
- Tranz-X Internal Dropper post w/ shifter-type remote, 7075 alloy, 31.6x100x360MM / 80x315MM for 14.5-inch frame
- Shifters
- Shimano Deore XT, SL-M8000-R, Right, 11-Speed, Clamp w/o gear display
- Tape/Grips
- Ritchey MTN Trail WCS LockRing, 135mm
- Color
- Electric Red/Black
- Size
- 20.5-inch
- Front Tire
- WTB Ranger, 27.5 x 2.8, Dual DNA, TCS, Aramid Bead 60 tpi
