- Subtype
- Trail / Enduro
- Category
- Mountain
- Component Fork
- FOX 36 Float Performance Elite Air FIT4 / 3-Modes With Low Speed Adj. / Kabolt 15x110mm Axle / 44mm Offset / Tapered Steerer / Rebound Adj. / Lockout / 150mm Travel
- Component Size
- Small, Medium, Large, X-Large
- Component Stem
- Syncros FL1.5 / Alloy 2014 / Integrated Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
- Product Family
- GENIUS
- Component Chain
- Shimano SLX CN-M7100
- Component Color
- Black
- Component Frame
- Genius Carbon / IMP Technology / HMF Main Frame / BB92 / Alloy SL 6011 swingarm / VLK Virtual 4-Link kinematic / 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) Tire Compatible With Geo-BB adj. / SW dropouts for Boost 12x148mm / TBC Trunnion Box Construction
- Component Brakes
- Shimano XT M8120 4-piston Disc
- Component Pedals
- Wellgo B155U SCT / Flat w/ Replaceable Pins
- Component Rotors
- Shimano SM-RT76 / 6-bolt / 203/F And 180/R
- Component Saddle
- Syncros Tofino 2.0 Regular / CrMo rails
- Component Headset
- Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm
- Component Crankset
- Shimano XT FC-M8100-1 / Hollowtech 2
- Component Seatpost
- FOX Transfer Performance Elite Dropper Post / 31.6mm / S 125mm / M & L 150mm / XL 175mm
- Component Shifters
- Shimano XT SL-M8100-IR / Rapidfire Plus / Ispec EV Clamp
- Component Handlebar
- Syncros Hixon 1.5 / Alloy 7050D.B. / 12mm rise / 9° / 780mm / Syncros Pro Lock-on Grips
- Component Rear Tire
- Front: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
Rear: Maxxis Rekon / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
- Component Wheel Set
- Syncros Revelstoke 2.0 6-bolt / F: 15x110mm, R: 12x148mm / 30mm Tubeless Ready Rim 28H / Micro Spline / Syncros Axle w/ Removable Lever With Tool
- Component Chainrings
- 32T
- Component Front Tire
- Front: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
Rear: Maxxis Rekon / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
- Component Rear Shock
- FOX NUDE TR EVOL Trunnion / SCOTT Custom W. Travel / Geo Adj. / 3 Modes: Lockout-Traction Control-Descend / Custom Ramp Adjust With Linear And Progressive Settings / DPS / Rebound Adj. / Travel 150-100-Lockout / 185X55mm
- Component Bottom Bracket
- Shimano SM-BB71-41A / Shell 41x92mm
- Component Rear Derailleur
- Shimano XT RD-M8100 SGS / Shadow Plus / 12 Speed
- Component Accessories Extras
- Fox 36 Fender / Syncros Eco Sealant / Transport Axle
- Component Cassette Freewheel
- Shimano XT CS-M8100-12 / 10-51 T
- Rear Shock
- FOX NUDE TR EVOL Trunnion / SCOTT Custom W. Travel / Geo Adj. / 3 Modes: Lockout-Traction Control-Descend / Custom Ramp Adjust With Linear And Progressive Settings / DPS / Rebound Adj. / Travel 150-100-Lockout / 185X55mm
- Crankset
- Shimano XT FC-M8100-1 / Hollowtech 2
- Pedals
- Wellgo B155U SCT / Flat w/ Replaceable Pins
- Bottom Bracket
- Shimano SM-BB71-41A / Shell 41x92mm
- Chain
- Shimano SLX CN-M7100
- Seatpost
- FOX Transfer Performance Elite Dropper Post / 31.6mm / S 125mm / M & L 150mm / XL 175mm
- Saddle
- Syncros Tofino 2.0 Regular / CrMo rails
- Handlebar
- Syncros Hixon 1.5 / Alloy 7050D.B. / 12mm rise / 9° / 780mm / Syncros Pro Lock-on Grips
- Headset
- Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm
- Rear Derailleur
- Shimano XT RD-M8100 SGS / Shadow Plus / 12 Speed
- Rear Tire
- Front: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
Rear: Maxxis Rekon / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
- Stem
- Syncros FL1.5 / Alloy 2014 / Integrated Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
- Accessories & Extras
- Fox 36 Fender / Syncros Eco Sealant / Transport Axle
- Brakes
- Shimano XT M8120 4-piston Disc
- Chainrings
- 32T
- Fork
- FOX 36 Float Performance Elite Air FIT4 / 3-Modes With Low Speed Adj. / Kabolt 15x110mm Axle / 44mm Offset / Tapered Steerer / Rebound Adj. / Lockout / 150mm Travel
- Frame
- Genius Carbon / IMP Technology / HMF Main Frame / BB92 / Alloy SL 6011 swingarm / VLK Virtual 4-Link kinematic / 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) Tire Compatible With Geo-BB adj. / SW dropouts for Boost 12x148mm / TBC Trunnion Box Construction
- Shifters
- Shimano XT SL-M8100-IR / Rapidfire Plus / Ispec EV Clamp
- Color
- Black
- Size
- X-Large
- Cassette/Freewheel
- Shimano XT CS-M8100-12 / 10-51 T
- Rotors
- Shimano SM-RT76 / 6-bolt / 203/F And 180/R
- Wheel Set
- Syncros Revelstoke 2.0 6-bolt / F: 15x110mm, R: 12x148mm / 30mm Tubeless Ready Rim 28H / Micro Spline / Syncros Axle w/ Removable Lever With Tool
- Front Tire
- Front: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
Rear: Maxxis Rekon / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C Maxx Terra
