Inspection
Frame condition
Inspect the frame, fork, welds, and high-stress areas for cracks, dents, or prior repairs.
Marin
2024 Marin Alpine Trail XR
Value Guide market data · 2024 Marin Alpine Trail XR
12-month trend
10%
Direction and magnitude, not judgment
vs. category average
— %
No category comparison available
Price over time - 2024 Marin Alpine Trail XR
Values based on actual sales data. Enter your bike's specifics to get a precise valuation.
All Alpine model years
2024$4,277 - $4,967Currently viewing
2023$3,347 - $3,887▼ 22% vs. 2024
2022$4,184 - $4,859▼ 2% vs. 2024
2020$3,627 - $4,212▼ 15% vs. 2024
2019$3,441 - $3,996▼ 20% vs. 2024
2013$911 - $1,058▼ 79% vs. 2024
2012$837 - $972▼ 80% vs. 2024
2011$781 - $907▼ 82% vs. 2024
2010$730 - $848▼ 83% vs. 2024
2007$456 - $529▼ 89% vs. 2024
1998$836 - $971▼ 80% vs. 20242024 Alpine Trail XR lineup
Overview
About this bike
2024 Marin Alpine Trail XR value depends on condition, original build, frame material, service history, and current buyer demand.
Specifications
Frameset
- Front Suspension
- RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset
- Rear Suspension
- {S=350lbs, M=350lbs, L=450lbs, XL=450lbs}
- Fork
- RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset
- Frame
- All New Series 4 6061 Aluminum, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs
- Rear Shock
- RockShox Super Deluxe Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune
Drivetrain
- Groupset
- SRAM GX
- Crankset
- SRAM GX Eagle, 32T, 55MM CL, 170MM Length
- Bottom Bracket
- SRAM DUB MTB 73
- Chain
- SRAM NX Eagle
- Cassette
- SRAM GX 1275 T-Type 10-52T
- Derailleur Rear
- SRAM GX Eagle Lunar 12-Speed
- Shift Lever
- SRAM GX Eagle Lunar MMX Mount
- Rear Derailleur
- SRAM GX Eagle Lunar
- Shifters
- SRAM GX Eagle Lunar MMX Mount
Brakes
- Brake Levers
- SRAM DB8 Hydraulic
- Brakes
- SRAM DB8 4-Piston Hydraulic Disc , HSC 200mm Rotor
Cockpit
- Handlebar
- Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
- Stem
- Marin CNC, 35mm Length, 35mm Bar Bore
- Grips
- Marin Grizzly Lock-On
- Headset
- FSA Custom, Adjustable HTA Design
- Seatpost
- {S=150mm, M=170mm, L=170mm, XL=200mm}
- Saddle
- Marin Speed Concept
Wheels & Tires
- Spokes
- 14g Black Stainless Steel
- Tires
- Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO+, Rear 27.5x2.5" DoubleDown, Tubeless compatible
- Rim
- Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible
- Hub Rear
- Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H
- Hub Front
- Formula, DC-711, 110x15mm, 6-Bolt Disc, 32h
- Front Tire
- Front: Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO+ , Rear: 27.5x2.5" DoubleDown, Tubeless compatible
- Hubs
- Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H
- Rear Tire
- Front: Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO+ , Rear: 27.5x2.5" DoubleDown, Tubeless compatible
- Wheel Set
- Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible
- Wheel Size
- 29-inch front, 27.5-inch rear
Accessories
- Extras
- Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head / Downtube Storage Bag
- Brakes Front
- SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor
- Brakes Rear
- SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor
Frame sizing
XS4'10"-5'2"
S5'2"-5'6"
M5'6"-5'10"
L5'10"-6'2"
XL6'2"-6'6"
M highlighted as most common resale size. Sourced from catalog metadata.
Geometry
- Stack
- Varies by size
- Reach
- Varies by size
- Wheelbase
- Varies by size
Industry standard. Sourced from catalog metadata.
What to check when buying used
Inspection
Drivetrain wear
Check chain stretch, cassette teeth, chainrings, and shifting under load before negotiating price.
Inspection
Wheel condition
Inspect rims, hubs, spokes, and bearing play; ask about the tire age and any prior wheel rebuilds.
Inspection
Service history
Ask for service records covering bearings, brakes, drivetrain, and any frame or fork warranty work.
Inspection
Suspension service
Confirm fork lowers and rear shock service intervals; ask for the most recent service receipts.
Inspection
Frame pivots & bearings
Cycle the suspension off the bike to feel for play, grit, or noise in pivot bearings.
