- Subtype
- Trail / Enduro
- Category
- Mountain
- Component Fork
- FOX 38 Float Performance Elite Air / FIT4 / 3-Modes With Low Speed Adj. / Kabolt 15x110mm axle / 44mm offset / Tapered Steerer / Rebound Adj. / Lockout / 170mm travel
- Component Size
- Small, Medium, Large, X-Large
- Component Stem
- Syncros XM1.5 / Alloy 6061 / Integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
- Product Family
- RANSOM
- Component Chain
- SRAM CN GX Eagle
- Component Color
- Black
- Component Frame
- Ransom Carbon / IMP Technology / HMX Main Frame / BB92 / Alloy SL 6011 Swingarm / VLK Virtual 4-Link Kinematic / 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) Tire Compatible With Geo-BB Adj. / SW Dropouts For Boost 12x148mm / TBC Trunnion Box Construction
- Component Brakes
- Shimano XT M8120 4-piston disc
- Component Pedals
- Sold separately
- Component Rotors
- Shimano SM-RT76 / 6-bolt / 203/F and 180/R
- Component Saddle
- Syncros Kaslo 1.5 / Titanium Rails
- Component Headset
- Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm
- Component Crankset
- SRAM GX Eagle DUB Boost
- Component Seatpost
- FOX Transfer Performance Elite Dropper Post / 31.6mm: S 125mm / M 150mm / L & XL 175mm
- Component Shifters
- SRAM GX Eagle Trigger / 12-speed
- Component Handlebar
- Syncros Hixon 1.5 Rise / Alloy 2014 D.B. / 20mm rise / 8° / 780mm
- Component Rear Tire
- Front: Maxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra
Rear: Maxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
- Component Wheel Set
- Syncros Revelstoke 2.0 6-bolt / F: 15x110mm, R: 12x148mm Boost / 30mm Tubeless Ready Rm 28H / XD Driver / Syncros Axle w/Removable Lever With Tool
- Component Chainrings
- 32T
- Component Front Tire
- Front: Maxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra
Rear: Maxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
- Component Rear Shock
- FOX NUDE TR EVOL Trunnion / SCOTT Custom W. Travel / Geo Adj. / 3 Modes: Lockout-Traction Control-Descend / Custom Ramp Adjust With Linear and Progressive Setting / DPS / Rebound Adj. / Travel 170-120-Lockout / 205X65mm
- Component Tape Grips
- Syncros Pro Lock-on Grips
- Component Bottom Bracket
- SRAM DUB PF Integrated / Shell 41x92mm
- Component Rear Derailleur
- SRAM GX / Eagle
- Component Accessories Extras
- Fox 38 Fender / Syncros Eco Sealant / Transport Axle
- Component Cassette Freewheel
- SRAM GX / XG1275 / 10-52T
- Rear Shock
- FOX NUDE TR EVOL Trunnion / SCOTT Custom W. Travel / Geo Adj. / 3 Modes: Lockout-Traction Control-Descend / Custom Ramp Adjust With Linear and Progressive Setting / DPS / Rebound Adj. / Travel 170-120-Lockout / 205X65mm
- Crankset
- SRAM GX Eagle DUB Boost
- Pedals
- Sold separately
- Bottom Bracket
- SRAM DUB PF Integrated / Shell 41x92mm
- Chain
- SRAM CN GX Eagle
- Seatpost
- FOX Transfer Performance Elite Dropper Post / 31.6mm: S 125mm / M 150mm / L & XL 175mm
- Saddle
- Syncros Kaslo 1.5 / Titanium Rails
- Handlebar
- Syncros Hixon 1.5 Rise / Alloy 2014 D.B. / 20mm rise / 8° / 780mm
- Headset
- Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm
- Rear Derailleur
- SRAM GX / Eagle
- Rear Tire
- Front: Maxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra
Rear: Maxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
- Stem
- Syncros XM1.5 / Alloy 6061 / Integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
- Accessories & Extras
- Fox 38 Fender / Syncros Eco Sealant / Transport Axle
- Brakes
- Shimano XT M8120 4-piston disc
- Chainrings
- 32T
- Fork
- FOX 38 Float Performance Elite Air / FIT4 / 3-Modes With Low Speed Adj. / Kabolt 15x110mm axle / 44mm offset / Tapered Steerer / Rebound Adj. / Lockout / 170mm travel
- Frame
- Ransom Carbon / IMP Technology / HMX Main Frame / BB92 / Alloy SL 6011 Swingarm / VLK Virtual 4-Link Kinematic / 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) Tire Compatible With Geo-BB Adj. / SW Dropouts For Boost 12x148mm / TBC Trunnion Box Construction
- Shifters
- SRAM GX Eagle Trigger / 12-speed
- Tape/Grips
- Syncros Pro Lock-on Grips
- Color
- Black
- Size
- X-Large
- Cassette/Freewheel
- SRAM GX / XG1275 / 10-52T
- Rotors
- Shimano SM-RT76 / 6-bolt / 203/F and 180/R
- Wheel Set
- Syncros Revelstoke 2.0 6-bolt / F: 15x110mm, R: 12x148mm Boost / 30mm Tubeless Ready Rm 28H / XD Driver / Syncros Axle w/Removable Lever With Tool
- Front Tire
- Front: Maxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra
Rear: Maxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
